29tecsis Operating Instructions - Pressure sensor P3297
BD_BE_BF_BSP 708 c
GB
Specifications Model P3297
Power supply U
B
DC
8 ... 30 V {DC 8 ... 35 V
1)
}
14 ... 30 V {DC 14 ... 35 V} with signal output 0 ... 10 V
5 V ± 10 % with signal output 0,5 ... 4,5 V ratiometric
Output signal and max. permissible
resistive loadR
A
R
A
in Ohm
4 ... 20 mA, 2-wire
R
A
≤ (U
B
– 8 V) / 0.02 A
0 ... 10 V, 3-wire
R
A
> 10 k
0 ... 5 V, 3-wire
R
A
> 5 k
1 ... 5 V, 3-wire
R
A
> 5 k
0.5 ... 4.5 V, 3-wire
R
A
> 4.5 k
0.5 ... 4.5 V ratiometric
R
A
> 4.5 k
{Other signal output on request}
Response time ms < 4
Current consumption mA
Signal current (max. 25) for current output
max. 8 for voltage output signal
Insulation voltage
2)
DC 500 V
Non-linearity % of span
≤
± 0.25 (BFSL) according to IEC 61298-2
≤
± 0.5 (BFSL) according to IEC 61298-2
Accuracy
3)
% of span
≤ ± 0.5
(with non-linearity 0.25 %)
≤ ± 0.6
(with non-linearity 0.25 % and with signal output 0 ... 5 V)
≤ ± 1.0
(with non-linearity 0.5 %)
Zero error for the zero signal % of span
≤
0.15 typ., ≤ 0.4 max., (with non-linearity 0.25 %)
≤
0.5 typ., ≤ 0.8 max., (with non-linearity 0.5 %)
Non-repeatability % of span
≤
0.1
Long-term drift % of span
≤ 0.1
according to IEC 61298-2
Signal noise % of span ≤ 0.3
Permissible temperature of
Medium
0 ... +80 °C
{-30 ... +100 °C}
Ambience
0 ... +80 °C
{-30 ... +100 °C}
Storage
-20 ... +80 °C
{-30 ... +100 °C}
Rated temperature range 0 ... +80 °C
Temperature error in
rated temperature range
% of span
≤
1.0 typ., ≤ 2.5 max.
Approvals cULus
3. Specifications
