30 tecsis Operating Instructions - Pressure sensor P3297
BD_BE_BF_BSP 708 c
GB
Specifications Model P3297
CE-conformity
Pressure equipment directive 97/23/EC
EMC directive
2004/108/EC, EN 61 326 Emission (Group 1, Class B) and
Immunity (industrial locations)
Shock resistance g 500 according to IEC 60068-2-27 (mechanical shock)
Vibration resistance g
10 according to IEC 60068-2-6 (vibration under resonance)
{20 g on request}
Wiring protection
Overvoltage protection DC 32 V; DC 36 V with 4 ... 20 mA
Short-circuit proofness S+ towards 0V
Reverse polarity protection U
B
towards 0V
Reference conditions according to IEC 61298-1
Operating conditions for internal and external operation
Relative humidity % up to 90
Weight g approx. 80
1) Not possible with non-linearity 0.25 % BFSL and 4 ... 20 mA
2) The power supply for the pressure sensor must be made via an energy-limited electrical circuit per section 9.3 of
UL / EN / IEC 61010-1, or an LPS to UL / EN / IEC 60950-1, or Class 2 per UL1310/UL1585 (NEC or CEC). The power supply must be
suitable for operation above 2,000 m should the pressure transmitter be used at this altitude.
3) Including non-linearity, hysteresis, zero-point and full scale value deviations (corresponds to measuring error per IEC 61298-2).
Calibrated in vertical mounting position with process connection facing downwards.
3. Specifications
