TECSYSTEM NT538 User Manual

26
NT538
INFO various causes (READ)
BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
-- -- -- - - -
-
(*) RESET (R)
has taken place
COMMANDS (WRITE)
BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
-- -- -- - -
(*) Reset
CPU_Error
(*) Reset
historical data
(*) Zero. BIT:
RESET has
taken place
CHn SETTING
BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
-- -- -- -- -- FAN2 FAN1 CAN_enabled
CHn STATUS
CHn STORY
BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
-- TRIP ALARM -- -- -- FOC FCC
RELAY STATUS (coil energizing status)
BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
-- -- --
FAULT relay
1=No fault
TRIP relay
1=ON
ALARM
relay 1=ON
FAN_2 relay
1=ON
FAN_1 relay
1=ON
CPU ERROR
BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
-- -- -- -- PT ERROR CAL FCD Fault ECH
CPU SETTING
BIT 7
BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
FAN MUX TRIP ALARM FAN_2 FAN_1 FCD FOC FCC
BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
-- -- --
Failsafe fault
(always=1)
Failsafe trip
Failsafe
alarm
-- --
