30 31
DO NOT TAKE MEASUREMENTS
WHILE AIMING THROUGH GLASS
SUCH AS WINDOWS, OR
GOLF CART WINDSHIELDS, ETC.
B) The distance shown in the larger
font will be the Actual Distance.
C) The distance shown in the smaller
font is the Slope Corrected Distance.
56Y
85Y
A) Angle
B) Actual distance
C) Slope corrected distance
SLOPE + PIN SEEKER MODE
B
56
Y
SCAN
-17
85
Y
A
C
31
