TECTOOL NTS 30 PREMIUM - Technical Data and Installation; Technical Specifications; Installation Steps

17
TECHNICAL DATA
Main
voltage
200
–
240V ~ 50 / 60 Hz
Power
1600 W
Maximum device socket power
2000 W
Total power
3600 W
Water tank capacity
30 L
Max.
air speed
65 L/s
Protection category
IPX4
Protection class
I
INSTALLATION
Installing the front wheels:
1. Open the quick coupling (Fig. 1 /Pos. 8) on both sides of the device and remove the machine head.
2. Put the water tank (Fig. 1 /Pos. 11) on the head.
3. Push the front wheels (Fig. 2 /Pos. 10) into the two openings on the bottom of the device.
Installing and removing the dust bag:
1. Push the clip back and pull the handle up. (Fig. 3)
2. Push the slider back. (Fig. 4)
3. Put the dust bag (Fig. 5 /Pos. 25) on the connection.
4. Release the slider. (Fig. 6)
3 filter system (Fig. 7):
Filter 1 – Coarse dust is caught by the dust bag.
Filter 2 – The dust is bound in water
Fill the water tank (Fig. 1 /Pos.11) up to the mark.
Filter 3 – The HEPA filter (Fig. 1 /Pos. 21) filters fine dust.
Inserting the filter:
1. Release the quick coupling (Fig. 1 /Pos. 8) on both sides of the device.
2. Push the selected filter in on the bottom of the machine head until it locks in place. (Fig .8)
- Foam filter (Fig. 1 /Pos. 20): suitable for wet vacuuming
- HEPA filter (Fig. 1 /Pos. 21): suitable for dry vacuuming
Installing the hose:
Dry vacuuming:
1. Insert the HEPA filter (Fig. 1 /Pos. 21).
2. Push the vacuum hose (3) onto the vacuum nozzle (3) and turn this clockwise. (Fig. 1)
3. Insert the cover for the hose connection (13) into the wet vacuuming connection. (Fig. 9).
Wet vacuuming:
1. Insert the foam filter (Fig. 1 /Pos.21).
2. Push the vacuum hose (2) into the connection on the water tank (11) and turn this clockwise.
3. Insert the hose connection cover (Fig.1/13) into the dry vacuuming connection
Air blasting:
1. Ensure that the water tank (Fig. 1 /Pos. 11) is completely drained and clean.
2. Push the vacuum hose (Fig. 1 /Pos. 2) into the blast nozzle (Fig. 1/Pos.16) and turn this clockwise.
Extraction unit for electrical devices:
1. Connect the dust extraction unit (Fig.1 /Pos. 22) to the electrical device and the vacuum hose (Fig. 1 /Pos. 2).
2. Push the vacuum hose (Fig. 1 /Pos.2) onto the vacuum nozzle (Fig. 1 /Pos. 3).
3. Plug the electrical device’s plug into the socket (Fig.1 /Pos.7).
