33
VERTICAL SHAFT ENGINES
STANDARD TVM ENGINE WITHOUT GOVERNOR
OVERRIDE
TVXL 220 WITH HORIZONTAL SPEED CONTROL
3029
TVS 115 ENGINE WITH "SNAP IN"
SPEED CONTROL
IDLE MIXTURE
SCREW
IDLE SPEED
CRACK SCREW
TNT 100 VERTICAL ENGINES
28
27
VERTICAL SHAFT ENGINES
HIGH SPEED
ADJUSTMENT
SCREW
IDLE SPEED
CRACK SCREW
BEND Ó TO INCREASE SPEED
BEND Ô TO DECREASE SPEED
26
