Page 10 Two-Cycle Engine • Horizontal/Vertical Crankshaft • Air-Cooled 181-1277-14
D. Cleaning/Replacing Air Filters
Your engine has an air cleaner which helps prevent
premature engine wear and failure. NEVER run engine
without complete air cleaner installed on engine. The filters
in the air cleaner periodically need to be cleaned or
replaced.
NOTE
Contact your Authorized Tecumseh Servicing Dealer for a
Tecumseh Air Cleaner.
I. Air Filter Removal/Installation
1. Remove screws. See Figure 21.
2. Remove filter cover.
3. Remove optional flocked screen, if present.
4. Remove foam filter.
5. Remove flocked screen.
6. Thoroughly clean the inside of filter cover and filter
body.
NOTE
DO NOT put oil on a flocked screen.
7. Inspect flocked screens and foam filter for discoloration
or dirt accumulation. If either is present, see “II.
Servicing Foam Filters” or “III. Servicing Flocked
Screens” instructions.
8. Install flocked screen.
9. Install foam filter.
10. Install optional flocked screen, if present.
11. Install filter cover.
12. Install screws and tighten securely.
II. Servicing Foam Filters
Clean and re-oil foam filters every 3 months or every 25
operating hours. Clean and re-oil daily if used in extremely
dusty conditions. After removing the filter, follow these
cleaning instructions below:
1. Wash in warm water and detergent solution then press
(DO NOT twist) until all dirt is removed.
2. Rinse thoroughly until water is clear.
3. Wrap in a clean cloth and press (DO NOT twist) until
completely dry.
4. Saturate with engine oil and press (DO NOT twist) to
distribute oil.
5. Remove excess oil.
III. Servicing Flocked Screens
1. Wash in a solution of water and detergent.
2. Rinse thoroughly in clear water. Air dry.
NOTE
DO NOT put oil on a flocked screen.
E. Remote Choke
See equipment manufacturer’s instructions and contact an
Authorized Tecumseh Servicing Dealer.
F. Carburetor
If you think your carburetor needs adjusting, see the
nearest Authorized Tecumseh Servicing Dealer. Engine
performance should not be affected at altitudes up to 7,000
feet (2,134 meters). For operation at higher elevations,
contact an Authorized Tecumseh Servicing Dealer.
G. Engine Speed
To avoid serious injury or death, DO
NOT modify engine in any way.
Tampering with the governor setting can lead to a runaway
engine and cause it to operate at unsafe speeds. NEVER
tamper with factory setting of engine governor. Running the
engine faster than the speed set at the factory can be
dangerous and will VOID THE ENGINE WARRANTY.
H. Adjustments
Do not make any engine adjustments. Factory settings are
satisfactory for most conditions. If adjustments are needed,
contact your Authorized Tecumseh Servicing Dealer.
I. Battery
See equipment manufacturer’s instructions for proper
battery storage, if present.
Figure 21. Air Filter Assembly
1. Screw
2. Foam Filter
3. Flocked Screen (Optional)
4. Flocked Screen
5. Filter Cover
1
2
3
4
5
1
