MODEL XQ140/20 HYDRAULIC POWER TONG OPERATION MANUAL
YANCHENG TEDA DRILLING & PRODUCTION EQUIPMENT CO.,LTD
Table 10.3 Shell and safety door accessory parts list
NO.
P/N
Parts number
Description
Qty.
1
XQ20-13
XQ20.1.4
Hanger rod
1
2
XQ20-14
XYQ12.Z-65
Jackscrew
4
3
XQ20-15
GB/T91
Cotter pin 5×40
2
4
XQ20-16
XYQ12.Z-63
Suspension pin shaft
2
5
XQ20-17
GB/T70.1
Hexagon socket head cap screw M10×25
20
6
XQ20-18
XQ20.1-38
Suspension seat
2
7
XQ20-19
XQ20.1-12
Front support seat
2
8
XQ20-20
GB/T93
Standard spring washer 12
10
9
XQ20-21
GB/T70.1
Hexagon socket head cap screw M12×25
4
10
XQ20-22
XQ20.1-8
Tong head cover
1
11
XQ20-23
XQ20.1-1
Shell
1
12
XQ20-24
XQ20.1-14
Pressure and torque corresponding plate
1
13
XQ20-25
XQ20.1-22
Bottom cover
1
14
XQ20-26
GB/T70.1
Hexagon socket head cap screw M8×20
6
15
XQ20-27
XQ20.1-21
End cover
1
16
XQ20-28
GB/T1152
Oil cupM10×1
1
17
XQ20-29
GB/T70.1
Hexagon socket head cap screw M6×16
6
18
XQ20-30
Pressure gage(
Φ
60,0-25MPa)
1
19
XQ20-31
XYQ12.B-30
Pressure gage connector
1
20
XQ20-32
Copper gasket Φ20×Φ14×3
4
21
XQ20-33
XYQ12.Z.6
Pressure transfer pipeline
1
22
XQ20-34
XYQ12.Z-40.02
Oil passage bolt
2
23
XQ20-35
GB/T5781
Hexagon bolt M12×30
4
24
XQ20-36
XYQ12.Z-44
Baffle plate(1)
2
25
XQ20-37
XQ20.1-13
Gear grade plate
1
26
XQ20-38
GB/T65
Slotted countersunk head screw M6×10
20
27
XQ20-39
GB/T5781
Hexagon boltM16×50
4
28
XQ20-40
GB/T93
Standard spring washer 16
4
29
XQ20-41
GB/T5781
Hexagon boltM12×15
1
30
XQ20-42
Hydraulic motor 6K-625
1
31
XQ20-43
GB1235-76
O ring 32
×
3.5
2
32
XQ20-44
XYQ12.Z-50
Transitional connection plate
1
33
XQ20-45
GB1235-76
O ring 22×2.4
2
34
XQ20-46
GB/T70.1
Hexagon socket head cap screw M12×30
14
35
XQ20-47
XQ20.1-25
Cabinet
1
36
XQ20-48
XYQ12.Z-21
Location block
1
