TEDA XQ140 - Page 33

MODEL XQ140/20 HYDRAULIC POWER TONG OPERATION MANUAL
YANCHENG TEDA DRILLING & PRODUCTION EQUIPMENT CO.,LTD
37
XQ20-49
XYQ3C.Z-21
Spring
1
38
XQ20-50
XYQ12.Z-60
Location seat
1
39
XQ20-51
GB/T93
Standard spring washer 8
2
40
XQ20-52
XQ20.1-24
Slider (lower)
1
41
XQ20-53
XQ20.1-23
Spring
1
42
XQ20-54
GB/T68
Slotted countersunk head screw M5
×
16
2
43
XQ20-55
XYQ12.Z-58
Flat key
2
44
XQ20（1）
-56
XQ20（1）.1-2
Tail seat
1
45
XQ20-57
XQ20.1-3
Tail seat pin
1
46
XQ20-58
Cotter pin 5×35
1
47
XQ20-59
XYQ12.Z-46
Baffle plate (2)
2
48
XQ20-60
XQ20.1-13
Product name plate
1
49
XQ20-61
XYQ3C.Z-37
Rear handle
4
50
XQ20-62
GB/T70.1
Hexagon socket head cap screw M10
×
20
8
51
XQ20-63
XQ20.1-35
Location plate
2
