MODEL XQ140/20 HYDRAULIC POWER TONG OPERATION MANUAL
YANCHENG TEDA DRILLING & PRODUCTION EQUIPMENT CO.,LTD
10.8Gear shifting assembly (lower) and parts list (Fig.10.8,Table 10.8)
Fig.10.8
Table10.8 Safety door assembly (lower) parts list
NO.
P/N
Parts number
Description
Qty.
1
XQ20-190
XYQ12.Z-19.01
Shaft sleeve
2
2
XQ20-191
XYQ12.Z-19.04
Stud shaft
2
3
XQ20-192
GB/T276
Deep groove ball bearing 6100
2
4
XQ20-193
GB/T848
Small washer 10
2
5
XQ20-194
XYQ12.Z-19.02
Shift fork
1
6
XQ20-195
GB/T93
Standard spring washer 10
2
7
XQ20-196
GB/T6170
Hexagon nutM10
2
8
XQ20-197
XQ20.1.6-1
Shift fork shaft
1
9
XQ20-184
XYQ3C.Z.5-10
Ball handle
1
10
XQ20-185
XYQ3C.Z.6-4
Roller shaft
1
11
XQ20-186
GB/T91
Cotter pin 2×10
1
12
XQ20-187
XYQ3C.Z.6-3
Roller
1
13
XQ20-188
XYQ3C.Z.6-5
Roller seat
1
14
XQ20-198
GB/T1096
Flat key 6
×
6
×
40
1
