Mount the adapter around the cylinder as shown below, making sure that the adhesive does not come into contact
with the cylinder, then press the adapter rmly against the door for 1 minute. You can now insert the key into the
cylinder.
1
2
3
Carefully remove the protective lm from the back
of the adapter, taking care not to touch the adhesive
tape, which may weaken its properties.
Thoroughly wipe the area around the lock cylinder
(rosette/escutcheon) with the cleansing wipe pad
provided and let it dry for about 1 minute.
1 min
Note: Make sure you install the adapter in a room with a temperature above 15 degrees Celcius.
