STEP 1: INSTALL ADAPTER (OPTIONAL)
ADAPTER NOT NEEDEDADAPTER NEEDED
ATTENTION: If your lock cylinder extends less than 3mm beyond the rosette/escutcheon, as shown in the picture below, follow
the steps for tting the adapter shown on the next page of the manual.
If your cylinder extends 3mm or more beyond the outline of the door, go straight to STEP 2: INSTALL TEDEE GO.
< 3 mm
< 3 mm
Follow the instructions below Proceed to step 2
>= 3 mm
>= 3 mm
SETUP - 5 EASY STEPS
USE THE RULER PROVIDED WITH THE TEDEE GO SET
TO TAKE MEASUREMENTS.
3MM
