Product
®
Figure 3: Plumbing Diagram - Diaphragm Pump
Boom 1
Boom 2
Boom 3
Boom Valves 1-3
Regulating Valve
Gauge Tee
Pressure Relief
Valve
Tank Shut Off
Line Strainer
Diaphragm Pump
Throttling Valve
To 744A
Controller
Jet Agitatior
Figure 4: Plumbing Diagram - Centrifugal Pump and Self-Cleaning Strainer
To 744A
Controller
Throttling Valve
Throttling
Valve
Gauge Tee
Tank
Shut-Off
Centrifugal
Pump
Throttling Valve
Line Strainer
Elecrical
Regulating
Valve
Directo Valve
Boom 1
Boom 2
Boom3
Jet Agitator
