Kit Contents
Unpack the installation kit and identify the required parts.
Item Part Number Description Quantity
1 67-20004 Tee Fitting, Nylon (Black) .................................................................................................................................................1
2 67-20003 Male Connector, Nylon ....................................................................................................................................................1
3 67-20002 Tubing Nut, Nylon ............................................................................................................................................................3
4 67-20005 Close Nipple, Nylon (Black) .............................................................................................................................................1
5 65-50005 Tubing Insert, Brass .........................................................................................................................................................4
6 64-50023 Mounting Bracket, Nylon ..................................................................................................................................................1
7 60-10026 Lock Knob ........................................................................................................................................................................2
8 60-50000 1/4” External Tooth Lock Washer ....................................................................................................................................2
9 60-50003 1” Bolt, Steel, Zinc Plated ................................................................................................................................................2
10 60-50001 Flat Washer, Steel, Zinc Plated ........................................................................................................................................2
11 60-50009 Lock Washer, Steel, Zinc Plated ......................................................................................................................................2
12 350-0062 Hex Nut, Steel, Zinc Plated ..............................................................................................................................................2
13 67-20001 Male Coupling, Nylon .......................................................................................................................................................1
14 90-50141 Accessory Bag - Items 2, 3 ,5, & 7-13 .............................................................................................................................1
15 75-50033 Control Housing 100 psi Liquid ........................................................................................................................................1
16 75-50035 Control Housing 300 psi Liquid ........................................................................................................................................1
17 98-70025 744A Manual ....................................................................................................................................................................1
Item Part # Description Illustration
A 67-20004 Tee Fitting, Nylon (Black)
B 67-20003 Male Connector, Nylon
C 67-20002 Tubing Nut, Nylon
D 67-20005 Close Nipple, Nylon (Black)
