For Repair Parts, call 1-800-323-0620
24 hours a day – 365 days a year
9
Teel Operating Instructions and Parts Manual 4RH36, 4RH37, 4RH38, 4RH39, and 4RH40
E
N
G
L
I
S
H
(*) Standard hardware item, available locally.
(▲) Included in Seal and Gasket Kit.
(●) Included in Trap Basket & O-Ring Kit.
(■) Included in Lock Handle Kit.
1 Motor - 115/230V 2K412 5U116 5U117 – – 1
230V – – – 5U118 5U153 1
2 Bonding lug U17-568 U17-568 U17-568 U17-568 U17-568 1
3 #10 - 32 x 1/2” Screw * * * * * 1
4A Shaft extension C110-17 C110-17 C110-17 C110-17 C110-17 1
4B 1/4 - 20 x 5/16” Set screw * * * * * 3
5 Adapter C2-57D C2-57D C2-57D C2-57D C2-57D 1
6 3/8” - 16 Hex nut * * * * * 4
7 3/8 - 16 x 1
1
⁄4” Stud U30-22SS U30-22SS U30-22SS U30-22SS U30-22SS 4
8 ▲ Gasket C20-72 C20-72 C20-72 C20-72 C20-72 4
9 ▲ Shaft seal U109-136SS U109-136SS U109-136SS U109-136SS U109-136SS 1
10 Impeller C5-164D C5-166D C5-183D C5-181D C5-182D 1
11 Volute and trap body C1-185DB C1-185DB C1-185DB C1-185DB C1-185DB 1
12 ● Trap basket C108-33P C108-33P C108-33P C108-33P C108-33P 1
13 ● Cord ring U9-161 U9-161 U9-161 U9-161 U9-161 1
14 Trap cover C3-140D C3-140D C3-140D C3-140D C3-140D 1
15 ■ Trap handle C154-18D C154-18D C154-18D C154-18D C154-18D 2
16 1/4” NPT Pipe plug * * * * * 2
17 3/8 - 16 x 3/4” Capscrew * * * * * 4
Service Kits
▲ Seal and gasket kit PP1150 PP1150 PP1150 PP1150 PP1150 1
■ Trap basket & O-Ring kit PP2061 PP2061 PP2061 PP2061 PP2061 1
● Lock handle kit PP2050 PP2050 PP2050 PP2050 PP2050 1
Ref. 4RH37 4RH39 4RH40 4RH38 4RH36
No. Description 3/4 HP 1 HP 1
1
⁄2 HP 2 HP 2
1
⁄2 HP Qty.
Repair Parts List
Limited Warranty
DAYTON ONE-YEAR LIMITED WARRANTY. Teel
®
self-priming pool/spa pumps, Models covered in this manual, are warranted by Dayton Electric Mfg. Co.
(Dayton) to the original user against defects in workmanship or materials under normal use for one year after date of purchase. Any part which is determined
to be defective in material or workmanship and returned to an authorized service location, as Dayton designates, shipping costs prepaid, will be, as the
exclusive remedy, repaired or replaced at Dayton’s option. For limited warranty claim procedures, see PROMPT DISPOSITION below. This limited warranty gives
purchasers specific legal rights which vary from jurisdiction to jurisdiction.
LIMITATION OF LIABILITY. To the extent allowable under applicable law, Dayton’s liability for consequential and incidental damages is expressly disclaimed.
Dayton’s liability in all events is limited to and shall not exceed the purchase price paid.
WARRANTY DISCLAIMER. Dayton has made a diligent effort to provide product information and illustrate the products in this literature accurately; however,
such information and illustrations are for the sole purpose of identification, and do not express or imply a warranty that the products are MERCHANTABLE, or
FIT FOR A PARTICULAR PURPOSE, or that the products will necessarily conform to the illustrations or descriptions.
Except as provided below, no warranty or affirmation of fact, expressed or implied, other than as stated in the “LIMITED WARRANTY” above is made or
authorized by Dayton.
PRODUCT SUITABILITY. Many jurisdictions have codes and regulations governing sales, construction, installation, and/or use of products for certain purposes,
which may vary from those in neighboring areas. While Dayton attempts to assure that its products comply with such codes, it cannot guarantee compliance,
and cannot be responsible for how the product is installed or used. Before purchase and use of a product, review the product applications, and all applicable
national and local codes and regulations, and be sure that the product, installation, and use will comply with them.
Certain aspects of disclaimers are not applicable to consumer products; e.g., (a) some jurisdictions do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you; (b) also, some jurisdictions do not allow a limitation on how long an implied
warranty lasts, consequently the above limitation may not apply to you; and (c) by law, during the period of this Limited Warranty, any implied warranties of
implied merchantability or fitness for a particular purpose applicable to consumer products purchased by consumers, may not be excluded or otherwise
disclaimed.
PROMPT DISPOSITION. Dayton will make a good faith effort for prompt correction or other adjustment with respect to any product which proves to be
defective within limited warranty. For any product believed to be defective within limited warranty, first write or call dealer from whom the product was
purchased. Dealer will give additional directions. If unable to resolve satisfactorily, write to Dayton at address below, giving dealer’s name, address, date, and
number of dealer’s invoice, and describing the nature of the defect. Title and risk of loss pass to buyer on delivery to common carrier. If product was damaged
in transit to you, file claim with carrier.
Manufactured for Dayton Electric Mfg. Co., 5959 W. Howard St., Niles, Illinois 60714 U.S.A.
®
