Teka HLB - Oven Components and Controls; Description of the Oven Components; Control Panel Overview

21
User’s Guide
10
11
12
13
14
15
4
5
6
7
8
3
2
English
Description of the oven
1
9
Control panel
1 2 3
1 Control panel
2 Door lock (only for
pyrolytic models)
3 Grill element
4 Tray supports
5 Grid shelf
6 Tray
7 Hinge
8 Inner Glass
9 Air cooling outlet
10 Unit mounting
11 Lamp
12 Back Wall Panel
13 Fan
14 Oven Seal
15 Door
1 Function control dial
2 Electric clock/timer
3 Temperature control dial
