Tekno EB48 2.2 - Page 14

Step
J-1
Step
J-2
Step
J-3
TKR9181T
TKR1323
TKR9062B
TKR9104
TKR1344
TKR1349
TKR1324
TKR1343
TKR1346
Thread
Lock
Note: Use assembly
from step I-4.
TKR1324
M3x12mm Flat Head Screw
x2
TKR1343
M4x10mm Flat Head Screw
x2
TKR1344
M4x12mm Flat Head Screw
x2
TKR1346
M4x15mm Flat Head Screw
x2
TKR1349
M4x20mm Flat Head Screw
x2
TKR9102A
TKR1323
M3x10mm Flat Head Screw
x1
TKR1344
Bag J
Front End Assembly
14
Note: Since the bumper is keyed
into the chassis, you must back
