LABORATORY
INSTRUMENT
DIVISION
C
5000
SERIES
5812N ,
5A13N ,
5B42
,
5B44 HELIDIAL
SETTINGS
Below are
the
mechanical
settings
of the
5000 Series
plug
- ins
"
Helidials "
.
All
settings are
stated
with the
pot set
fully counter
clockwise
.
5A13N
0.00
5B12N
0.20
5B42
0.20
:
5344
0.20
--John Eaton
58/511
,
Ext ,
6902
C
-9 .
June 27 , 1980
Issue 10-13
