Tektronix AFG3011 Technical Reference

Performance verification
4. Set up the spectrum analyzer according the frequency setup of the arbitrary
function generator.
5. Set the Ref Level of the spectrum analyzer to 8 dBm.
6. Read the signal level in the Fundamental frequency for each signal. Use this
level as a Reference value in step 7.
7. Verify that the differences between the reference level and the signal level in
the frequency of higher-order at each frequency are below the limit specified
in the following tables.
8. (Two channel models only) Repeat steps 2 through 4 for the channel 2
output.
AFG3011 /
3011C Spectrum Analyzer Measurem ent Limit
Frequency
Center
Frequency
Span
RBW Fundamental
(=
Reference)
2nd 3rd 4th 5th Nth -
Reference
20.00 kHz 100 kHz 200 kHz 500 Hz 20 kHz 40 kHz 60 kHz 80 kHz 100 kHz < -55 dBc
100.00 kHz 500 kHz 1 MHz 2 kHz 100 kHz 200 kHz 300 kHz 400 kHz 500 kHz < -55 dBc
1.00 MHz 5.00 MHz 10 MHz 20 kHz 1 MHz 2 MHz 3 M Hz 4 MHz 5 MHz < -45 dBc
10.00 MHz
10 MHz/
50 MHz
20 MHz/
100 MHz
20 kHz/
20 kHz
10 MHz 20 MHz 30 MHz 40 MHz 50 MHz < -45dBc
AFG302xB
/ 302xC Spectrum Analyzer M easurem ent Limit
Frequency
Center
Frequency
Span
RBW Fundamental
(=
Reference)
2nd 3rd 4th 5th Nth -
Reference
20.00 kHz 100 kHz 200 kHz 500 Hz 20 kHz 40 kHz 60 kHz 80 kHz 100 kHz < -60 dBc
100.00 kHz 500 kHz 1 MHz 2 kHz 100 kHz 200 kHz 300 kHz 400 kHz 500 kHz < -60 dBc
1.00 MHz 5.00 MHz 10 MHz 20 kHz 1 MHz 2 MHz 3 MHz 4 MHz 5 MHz < -50 dBc
25.00 MHz 125 MHz 250 MHz 20 kHz 25 MHz 50 MHz 75 MHz 100 MHz 125 MHz < -40 dBc
AFG305xC Spectrum Analyzer Measurement Limit
Frequency
Center
Frequency
Span
RBW Fundamental
(=
Reference)
2nd 3rd 4th 5th Nth -
Reference
100 kHz 500 kHz 1 MHz 2 kHz 100 kHz 200 kHz 300 kHz 400 kHz 500 kHz < -60 dBc
1 MHz 5.00 MHz 10 MHz 20 kHz 1 MHz 2 MHz 3 MHz 4 MHz 5 MHz < -50 dBc
5 MHz
10 MHz /
25 MHz
20 MHz
/
50 MHz
20 kHz /
20 kHz
5 MHz 10 MHz 15 MHz 20 MHz 25 MHz
< -40 dBc
25 MHz 125 MHz 250 MHz 20 kHz 25 MHz 50 MHz 75 MHz 100 MHz 125 MHz
< -40 dBc
50 MHz 500 MHz
1GHz
100 kHz 100 MHz 200 MHz 300 MHz 400 MHz 500 MHz < -40 dBc
60 AFG3000C and AFG3000 Series Specifications and Performance Verification
