Tektronix AFG3011C

Specifications
Table 9: Internal noise add
Characteristic Description
Range
0% to 50% of amplitude setting
Resolution
1%
Table 10: Output characteristics
Characteristic Description
PV reference
page
Sine wave
Flatness (at 1.0 V
p-p
amplitude (+4 dB m), relative to 1 kHz)
(See page 56,
AC Flatness
test.)
AFG3011 / 3011C
<5MHz: ±0.15dB
5MHz≤ frq ≤ 10 MHz: ±0.3 dB
AFG3021B / 3021C /
3022B / 3022C
<5MHz: ±0.15dB
5MHz≤ frq < 20 MHz: ±0 .3 dB
20 MHz ≤ frq ≤ 25 MHz: ±0.5 dB
AFG3051C / 3052C
<5MHz: ±0.15dB
5MHz≤ frq < 45 MHz: ±0 .3 dB
45MHz ≤ frq ≤ 50 MHz: ±0.5 dB
AFG3101 / 3101C / 3102
/ 3102C
<5MHz: ±0.15dB
5MHz≤ frq < 25 MHz: ±0 .3 dB
25 MHz ≤ frq ≤ 100 MHz: ±0.5 dB
AFG3151C / 3152C
<5MHz: ±0.15dB
5MHz≤ frq < 25 MHz: ±0 .3 dB
25 MHz ≤ frq ≤ 150 MHz: ±0.5 dB
AFG3251 / 3251C / 3252
/ 3252C
<5MHz: ±0.15dB
5MHz≤ frq < 25 MHz: ±0 .3 dB
25 MHz ≤ frq < 100 MHz: ±0.5 dB
100 MHz ≤ frq < 200 MHz: ±1.0 dB
200 MHz ≤ frq ≤ 240 MHz: ±2.0 dB
Harmonic distortion (at 1.0 V
p-p
amplitude)
(See page 59,
Harmonics
Distortion test.)
AFG3011 / 3011C 10 Hz ≤ frq < 20 kHz: < –60 dBc
20 kHz ≤ frq < 1 MHz: < –55 dB c
1MHz≤ frq ≤ 10 MHz: < –45 dBc
AFG3021B / 3021C /
3022B / 3022C
10 Hz ≤ frq < 20 kHz: < –70 dBc
20 kHz ≤ frq < 1 MHz: < –60 dB c
1MHz≤ frq < 10 MHz: < –50 dBc
10 MHz ≤ frq ≤ 25 MHz: < –40 dBc
AFG3000C and AFG3000 Series Specifications and Performance Verification 11
