TAS 200 Series Specifications
Handheld and Benchtop Instruments Basic Service
3
Table 1: Vertical Deflection Characteristics (Cont.)
Characteristic TAS 250 DescriptionTAS 220 Description
Chopping Repetition Frequency (Typical) 250 kHz
Maximum Input Voltage 400 V (DC + peak AC)
Channel Isolation (Typical) 50 kHz: 1000:1
10 MHz: 100:1
20 MHz: 30:1 50 MHz: 30:1
CH 1 Signal Output (Typical) 100 mV/div open circuit
50 mV/div into 50 W
CH 2 INV Balance (Typical) ≤1 division balanced point variation
Table 2: Horizontal Characteristics TAS 200 Series
Characteristic
Description
Standard Sweep Time Accuracy 15° to 35° C: ±3%
0° to 15° C and 35° to 40° C: ±4%
Magnified Sweep Time Accuracy 1 ms/div to 0.5 sec/div: ±5%
0.1 to 0.5 ms/div: ±8%
Sweep Linearity
Standard ±3%
X10 MAG ±5%
X10 MAG 0.1 to 0.5 ms/div: ±8%
Table 3: Readout Characteristics TAS 200 Series
Characteristic Description
Readout Resolution 1/25 div
Readout Accuracy ±3% + 1/25 div
Readout Modes DV, DT, 1/DT
