DMM800 Series Performance Verification
16
Handheld and Benchtop Instruments Basic Service
4. Set the calibrator to each of the values in the Volts Peak Hold Test record and
verify that the multimeter reads within the specified Display Minimum and
Maximum limits.
5. Set the calibrator output to OFF.
6. Disconnect the calibrator from the multimeter.
Perform the following steps to verify the DC milliampere measurement accuracy.
1. Set the multimeter dial to mA
.
2. Connect the calibrator outputs to the multimeter mA mA and COM input
connectors.
3. Set the calibrator to each of the values in the DC Milliampere Test record
and verify that the multimeter reads within the specified Display Minimum
and Maximum limits.
4. Set the calibrator output to OFF.
5. Disconnect the calibrator from the multimeter.
Perform the following steps to verify the AC milliampere measurement accuracy.
1. Set the multimeter dial to mA
.
2. Push the BLUE button to select AC mode.
3. Connect the calibrator outputs to the multimeter mA mA and COM input
connectors.
4. Set the calibrator to each of the values in the AC Milliampere Test record
and verify that the multimeter reads within the specified Display Minimum
and Maximum limits.
5. Set the calibrator output to OFF.
6. Disconnect the calibrator from the multimeter.
Perform the following steps to verify the DC ampere measurement accuracy.
1. Set the multimeter dial to A
.
2. Connect the calibrator outputs to the multimeter A and COM input
connectors.
3. Set the calibrator to each of the values in the DC Ampere Test record and
verify that the multimeter reads within the specified Display Minimum and
Maximum limits.
DC Milliampere Check
AC Milliampere Check
DC Ampere Check
