Commands Listed in Alphabetical Order
MINImum specifi
es that the waveform persistence is set to the minimum value
of 0.0E0.
Examples
DISPLAY:PER
SISTENCE 3
specifies that the waveform points are displayed
fading for 3 seconds before they completely disappear.
D<x>
Sets or returns parameters for digital channel <x>, where x is the channel number.
Group
MSO
Syntax
D<x>
D<x>:LABel
Sets or returns the waveform label for digital channel <x>, where x is the channel
number.
Group
MSO
Syntax
D<x>:LABel <Qstring>
D<x>:LABel?
Arguments
<Qstring> is an alpha-numeric string of text, enclosed in quotes, that contains
the text label information for the digital channel <x> waveform. The text string is
limited to 30 characters.
Examples
D4:LABEL? might return :D4:LABEL “Clk Wfm 4”.
D<x>:POSition
Sets or returns the vertical position for digital channel <x>, where x is the channel
number.
NOTE. Unlike analog channels, which use the center baseline a s the zero point,
digital channels use the bottom logic level a s the zero point. Because of the slot
model used to describe digital channel position, the oscilloscope rounds off
divisions to the nearest slot.
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 2-145
