Giving Demos of MSO Features
7. Push Height to select L (large).
D15-D0
On/Off
Thresholds Edit Labels MagniVu
On |
Off
Height
SM|
L
8. Push Autoset.
9. Turn the Horizontal Scale knob to select 1 μs
asthetimeperdivision.
10. Turn the channel 1 Vertical Position knob to
position the analog channel 1 waveform near
the m id dle of the top half of the graticule, if it is
not alrea dy there.
Demo 2 Board Instruction Manua l 107
