Performance Verification
3. Push the front-
panel Trigger Menu button.
4. Push the lower-bezel Coupling button, and then push the Noise Reject (DC
Low Sensitivi
ty) side-bezel b utton.
5. Push the Menu Off button 2 times, so you can see the screen.
6. Push the front-panel Trigger Menu button.
7. Push the lower-bezel Source button and use Multipurpose knob a to select the
channel being tested as the trigger source.
8. Push the channel button (1, 2, 3, or 4) for the channel that you want to check.
9. Push the lower-bezel Probe Setup button, and then push the Setto1X
side-bezel button.
10. Push the front-panel Measure button, and then push the bottom-bezel Add
Measurement button.
11. Use Multipurpose knob a to select the Peak-to-peak measurement, and then
push the OK Add Measurement side-bezel button.
12. Push the Menu Off button 2 times, so you can see the screen.
13. Turn the Vertical Scale knob to set the vertical scale to 500 mV/div.
14. Turn t
he Horizontal Scale knob to 400 μs/div.
15. Set the leveled sine wave generator frequency to 1kHz.
16. Set the leveled sine wave generator output level so the peak-to-peak
measurement is between 2.98 V and 3.02 V.
17. Set the leveled sine wave generator to the frequency shown for the
oscilloscope model:
Model Frequency
DPO2024, MSO2024
200 MHz
DPO2012, DPO2014, MSO2012, MSO2014
100 MHz
18. Use the Horizontal Scale knob to set the oscilloscope to 10 ns/div.
19. Check that the peak-to-peak measurement is ≥2.12 V. Enter this measurement
in the test record.
20. Move the input cable to the next channel to be tested.
21. Repeat steps 6 through 20 for each remaining channel.
22 DPO2000 and MSO2000 Series Specifications and Performance Verifi cation
