Clear and Sanitize Procedures
Table 2: Nonvol
atile Memory Devices for the DPO2000/B and MSO2000/B Series
Type and minim um size Function User modifiable
Data input
method Location To c lear or sanitize
CMOS, FLASH; 16M X 8 OR
8M X 16, 128MBIT, 75NS, 3V;
PC28F128J3D-75, BGA64
FLASH: contains the
instrument firmware,
calibration constants,
reference waveforms,
and instrument setups
N/A N/A
Acquisition board To clear: Not applicable
for calibration constants.
Use t he TekSecure
featuretoerase
reference waveforms
and instrument setups.
Use the procedure to
disable the LAN Ethernet
and to clear information,
such as IP addresses.
(See page 5, Disable the
LAN Port and Clear LAN
Ethernet Settings.)
To sanitize: Remove
the acquisition board;
see the product service
manual for removal
instructions. Store the
removed board in a
secure area or destroy
it. Return the product
to Tektronix and a
new acquisition board
will be installed and
the instrument will be
repaired and adjusted as
necessary.
CMOS, C LOCK; SERIAL
REAL-TIME CLOCK,
CRYSTAL, 7 X 8 RAM, SPI,
3.3V; M41T93RMY, SO18.300
Real-time clock, with
battery backup
Only by the
processor system
N/A
Acquisition board Not applicable; no user
data
CMOS, EEPROM; 128 X 8,
SERIAL; 24C01A, SOIC8
EEPROM: contains the
front end board serial
number and calibration
information
N/A N/A
Front End Board Not applicable; no user
data
CMOS, MICROCONTROLLER;
8-BIT, 32K BYTES ON-CHIP
FLASH, MC9S08AW32CPUE,
LQFP64
Microcontroller with
FLASH: contains the
front panel processor
code and power status
for soft power switch
Only by the
processor system
N/A
Front Panel Board Not applicable; no user
data
CMOS, EEPROM; 256 X 8,
SERIAL; 24C02, SO8.15
EEPROM: contains
the application module
firmware
N/A N/A DPO2000/B and
MSO2000/B application
module
Not applicable; no user
data
2 DPO2000/B and MSO2000/B Series Declassification and Security Instructions
