Tektronix DPO2012 Programmer's Manual

Command Groups
Table 2-31: Trigger Commands (cont.)
Command
Description
TRIGger:A:BUS :B<x>:LIN:ID entifier:VALue Sets or returns the binary
address string used for LIN
trigger
TRIGger:A:BUS :B<x>:I2C:ADDRess:MODe Sets or returns the I2C
address mode to 7 or 10-bit
TRIGger:A:BUS:B<x>:I2C:ADDRess:TYPe Sets or returns the I2C
address type to USER
TRIGger:A:BUS:B<x>:I2C:ADDRess:VALue Sets or returns the binary
address string used for the
I2C trigger
TRIGger:A:BUS :B<x>:I2C:C ON Dition Sets or returns the trigger
condition for I2C trigger
TRIGger:A:BUS :B<x>:I2C:D ATa:DIRection Sets or returns the I2C
trigger condition valid on a
READ, WRITE, or either
TRIGger:A:BUS :B<x>:I2C:D ATa:SIZe Sets or r eturns the length of
thedatastringinbytestobe
used for I2C trigger
TRIGger:A:BUS:B<x>:I2C:DATa:VALue Sets or returns the binary
datastringusedforI2C
triggering
TRIGger:A:BUS:B<x>:PARallel:VALue Sets or returns the binary
datastringtobeusedfora
parallel trigger
TRIGger:A:BUS:B<x>:RS232C:CONDition Sets or returns the c ondition
for a RS232C trigger
TRIGger:A:BUS:B<x>:RS232C:RX:DATa:SIZe Sets or returns the length of
the data string in Bytes for a
RX RS232 Trigger
TRIGger:A:BUS:B<x>:RS232C:RX:DATa:VALue Sets or returns the binary
data string for a RX RS232
trigger
TRIGger:A:BUS:B<x>:RS232C:TX:DATa:SIZe Sets or returns the l ength
of the data string for a TX
RS232 trigger
TRIGger:A:BUS:B<x>:RS232C:TX:DATa:VALue Sets or returns the binary
data string for a RS232
trigger if the trigger condition
involves TX
TRIGger:A:BUS:B<x>:SPI:C ONDition Sets or returns the trigger
condition for SPI triggering
TRIGger:A:BUS:B<x>:SPI:DATa{:IN|:MISO}:VALue Sets or returns the binary
datastringtobeusedforSPI
trigger
2-42 MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
