Tektronix DPO2012 Programmer's Manual

Command Groups
Table 2-31: Trigger Commands (cont.)
Command
Description
TRIGger:A:PULse:CLAss Sets or returns the type of
pulse on which to trigger
TRIGger:A:PULSEWIDth?
Returns the trigger A pulse
width parameters
TRIGger:A:PULSEWidth:POLarity Sets or returns the polarity
for the A pulse width trigger
TRIGger:A:PULSEWidth:SOUrce Sets or returns the source
for the pulse width trigger
TRIGger:A:PULSEWidth:WHEn Sets or returns the criteria for
width specification of pulse
width trigger events
TRIGger:A:PULSEWidth:WIDth Sets or returns the width
setting for the pulse width
trigger
TRIGger:A:RUNT ?
Returns the current A
runt pulse trigger logic
parameters
TRIGger:A:RUNT:POLarity Sets or returns the polarity
for the A pulse runt trigger
TRIGger:A:RUNT:SOUrce Sets or returns the source
for the A pulse trigger
TRIGger:A:RUNT:WHEn Sets o r returns the type
of pulse width the trigger
checks for when it uncovers
a runt
TRIGger:A:RUNT:WIDth Sets o r returns the m inimum
width for A pulse runt trigger
TRIGger:A:SETH old? Returns settings for setup
and hold violation triggering
TRIGger:A:SETHo ld:C LOCk?
Returns clock edge polarity,
voltage threshold and source
input for setup/hold triggering
TRIGger:A:SETHo ld:C LOC k:ED G E Sets or returns the clock
edge polarity for setup and
hold triggering
TRIGger:A:SETHo ld:C LOC k:SOUrce Sets or returns the clock
source for the A logic trigger
setup and hold input
TRIGger:A:SETHold:CLOCk:THReshold Sets or returns the clock
voltage threshold for setup
and hold trigger
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 2-45
