Tektronix DPO2012 Programmer's Manual

Command Groups
Table 2-31: Trigger Commands (cont.)
Command
Description
TRIGger:A:LOGIc:INPut:C H<x> Specifies or returns the
logic setting for the specified
channel
TRIGger:A:LOGIc:INPut:D <x> Sets or returns the logic
pattern for a trigger on digital
channel <x>, where x is the
channel number
TRIGger:A:LOGIc:INPut:C LOCk:EDGE Sets the polarity of the clock
channel.
TRIGger:A:LOGIc:INPut:C LOCk:SOUrce Sets or returns the channel
to use as the clock source
TRIGger:A:LOGIc:PATtern? Returns the conditions for
generating an A logic pattern
trigger
TRIGger:A:LOGIc:PATtern:DELTatime Sets or returns the pattern
trigger delta time value
TRIGger:A:LOGIc:PATtern:INPut:D<x> Sets or returns the A logic
trigger input for the specified
digital channel <x>, where x
is the channel number.
TRIGger:A:LOGIc:PATtern:WHEn Sets or returns the pattern
logic condition on which to
trigger the o scilloscope
TRIGger:A:LOGIc:PATtern:WHEn:LESS Limit Sets or returns the maximum
time that the selected pattern
may be true and still generate
an A logic pattern trigger
TRIGger:A:LOGIc:PATtern:WHEn:MOR ELim it Sets or returns the m inimum
time that the selected pattern
may be true and still generate
an A logic pattern trigger
TRIGger:A:LOGIc:THReshold:(CH<x>|D<x>) Sets or queries the logic
trigger threshold voltage for
the specified channel
TRIGger:A:LOWerthreshold:CH<x> Sets or returns the lower
threshold for the c hannel
selected
TRIGger:A:LOWerthreshold{:EXT|:AUX} Sets or returns the lower
threshold for the Auxiliary
input.
TRIGger:A:MO De Sets or returns the A trigger
mode
TRIGger:A:PULse?
Returns the A pulse trigger
parameters
2-44 MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
