Commands Listed in Alphabetical Order
Syntax
TRIGger:A:BUS
:B<x>:CAN:DATa:VALue <QString>
TRIGger:A:BUS:B<x>:CAN:DAT a:VALue?
Arguments
<QString> is the CAN data value in binary format. The only allowed characters
in the
QString are0,1,andX.
Examples
TRIGGER:A:BUS:B1:CAN:DATA: VALUE 1011 sets the CAN data value to 1011.
TRIGger:A:BUS:B<x>:CAN:FRAMEtype
Sets or returns the frame type for a CAN FRAMEType trigger. Applies to bus
<x>, where x is the bus number.
Conditions
This command require
s a DPO2AUTO application module. This command is
only valid when the TRIGger:A:BUS:B<x>:CAN:CONDition is FRAMETYPE.
Group
Trigger
Syntax
TRIGger:A:BUS:B<x>:CAN:FRA MEtype
{DATA|REMote|ERRor|OVERLoa d}
TRIGger:A:BUS:B<x>:CAN:FRA MEtype?
Arguments
DATA specifiesadataframetype.
REMote specifiesaremoteframetype.
ERRor specifies an error frame type.
OVERLold specifies an overload frame type.
Examples
TRIGGER:A:BUS:B1:CAN:FRAME TYPE DATA sets the CAN trigger frame type
to DATA.
TRIGger:A:BUS:B<x>:CAN{:IDentifier|:ADDRess}:MODe
Sets or returns the CAN addressing mode for bus <x>, where x is the bus number.
Use this command to do the following:
Trigger on ID
Trigger in ID ANDDATA
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 2-299
