Tektronix DPO2024 Programmer's Manual

Commands Listed in Alphabetical Order
MEASUrement:
IMMed:DELay:DIRection
Sets or returns the starting point and direction that determines the delay "to" edge
when taking an immediate delay measurement.
NOTE. Use th
e MEASUrement:IMMed:SOUrce2 command to specify the delay
"to" waveform.
Group
Measureme
nt
Syntax
MEASUrement:IMMed:DELay:D IRection {BACKWards|FORWa rds}
MEASUrement:IMMed:DELay:D IRection?
Related Commands
MEASUrement:IMMed:SOUrce2
Arguments
BACKWards starts the search at the end o f the waveform and looks for the last
rising or falling edge in the waveform.
FORWards starts the search at the beginning of the waveform and looks for the
first rising or falling edge in the waveform.
Examples
MEASUREMENT:IMMED:DELAY:D IRECTION FORWARDS starts s earching from the
beginning of the waveform record and looks for the first rising or falling edge.
MEASUREMENT:IMMED:DELAY:D IRECTION? might return
:MEASUREMENT:IMMED:DELAY: DIRECTION BACKWARDS indicating
that searching begins at the end of the waveform record and looks for the last
rising or falling edge.
MEASUrement:IMMed:DELay:EDGE<x>
Sets or returns the slope of the edge the oscilloscope uses for the delay "from" or
"to" waveform when taking an immediate d elay measurement.
Group
Measurement
Syntax
MEASUrement:IMMed:DELay:E DGE<x> {FALL|RISe}
MEASUrement:IMMed:DELay:E DGE<x>?
2-188 MSO2000B, DPO2000B, M SO2000 and DPO2000 Series Oscilloscopes Programmer Manual
