Commands Listed in Alphabetical Order
Syntax
MEASUrement:R
EFLevel:PERCent:HIGH <NR3>
MEASUrement:REFLevel:PERC ent:HIGH?
Related Commands
MEASUrement:REFLevel:METHod, MEASUrement:IMMed:TYPe,
MEASUrement:MEAS<x>:TYPe
Arguments
<NR3> is the high reference level, ranging from 0 to 100%. The default high
reference level is 90%.
Examples
MEASUREMENT:REFLEVEL:PERC ENT:HIGH 95 sets the high reference level
to 95% of HIGH
.
MEASUREMENT:REFLEVEL:PERC ENT:HIGH? might return
:MEASUREME
NT:REFLEVEL:PERCENT:HIGH 90
indicating that the
percentage high reference level is set to 90% of HIGH.
MEASUrement:REFLevel:PERCent:LOW
Sets or returns the percent (where 100% is equal to HIGH) used to calculate the
low reference level when MEASUrement:REFLevel:METHod is set to Percent.
This command affects the results of rise and fall measurements.
NOTE. t
his command affects the associated reference level parameter for all
MEASurements:IMMed and the four periodic measurements.
Group
Measu
rement
Syntax
MEASUrement:REFLevel:PERC ent:LOW <NR3>
MEASUrement:REFLevel:PERC ent:LOW?
Related Commands
MEASUrement:REFLevel:METHod, MEASUrement:IMMed:TYPe,
MEASUrement:MEAS<x>:TYPe
Arguments
<NR3> is the low reference level, ranging from 0 to 100%. The default low
reference level is 10%.
Examples
MEASUREMENT:REFLEVEL:PERC ENT:LOW 15 sets the high reference level to
15% of HIGH .
2-212 MSO2000B, DPO2000B, M SO2000 and DPO2000 Series Oscilloscopes Programmer Manual
