Commands Listed in Alphabetical Order
Examples
MEASUREMENT:M
EAS2:SOURCE1 MATH1
specifies Math 1 as the measurement
2 source.
MEASUREMENT:
MEAS1:SOURCE1?
might return
:MEASUREMENT:MEAS1:SOURCE[ 1] MATH1 indicating that Math1 is the
measurement 2 source.
MEASUremen
t:MEAS<x>:SOURCE2
Sets or returns the reference source to measure "to" when taking a delay
measurement or phase measurement. Measurements are specified by <x>, which
ranges fr
om 1 through 4.
NOTE. Source2 measurements only apply to phase and delay measurement types,
which require both a target (Sourc e1) and reference (Source2) source.
Group
Measurement
Syntax
MEASUrement:MEAS<x>:SOURCE 2 {CH<x>|MATH<y>|REF<x>}
MEASUrement:MEAS<x>:SOURCE 2?
Related Commands
MEASUrement:MEAS<x>:TYPe
Arguments
CH<x> is an input channel waveform, where x is the channel number.
MATH<y> is the math waveform, which is always 1.
REF<x> is a reference waveform, where x is the reference channel number.
Examples
MEASUREMENT:MEAS4:SOURCE2 CH1 specifies CH1 as the delay "to" source
when making delay measurement.
MEASUREMENT:MEAS2:SOURCE2? might return
:MEASUREMENT:MEAS2:SOURCE2 MATH1 indicating that Math 1 is the
measurement 2 source.
MEASUrement:MEAS<x>:SOUrce<x>
For SOURce1: Sets or returns the source for all single channel measurements. For
delay or phase measurements, sets or returns the waveform to me asure "from".
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 2-201
