Tektronix DPO4032 Demo Instruction Manual

Getting Started with th e Tektronix 4000 Series
5. Push t he front-panel Select button.
This lets you expand or contract your view into
the content s of the drive tha t you are using.
Expanded list Contracted list
6. Select the desired file format with the
side-bezel bu tton.
File Format
.png
7. Push OK Save Screen Image .
OK
Save
Screen
8. To easily save multiple images, push the
front-panel Save bu tton.
By default, the lower-bezel Assign Save to
button is set to Image.
18 Tektronix 4000 Oscilloscope Demo Instruction Manual

Tektronix DPO4032 Specifications

General

Brand	Tektronix
Model	DPO4032
Category	Test Equipment
Language	English
