Acquire the Signal
8. Push Select or Enter Ch aracter to let the
oscilloscope know that you have picked the
proper character to use.
You can use the lower-bezel buttons to edit
the label as needed.
Enter
Character
Back
Space
Delete
Clear
9. Continue scrolling and pushing Select until
you have entered all the desired characters.
For another label, push the side- and
lower-bezel arrow keys to re position the
insertion point.
10. Push Display L abels and select On to see
the label.
Display
Labels
On|Off
88 MSO4000 and DPO4000 S eries Oscilloscopes User Manual
