Tektronix DPO4054 Demo Instruction Manual

Giving Demos of Advanced Tektronix 40 00 Features
You a re now looking at the clock (yellow
ch1) and data (blue ch2) lines of an I
2
C
bus.
Hint: If the waveforms do not look like the
display to the right, go back to step 1 and
confirm th at you connected both probes to
the correct pins on the demo board.
28 Tektronix 4000 Oscilloscope Demo Instruction Manual

Tektronix DPO4054 Specifications

General

Brand	Tektronix
Model	DPO4054
Category	Test Equipment
Language	English
