Tektronix DPO4054 Demo Instruction Manual

Giving Demos of Advanced Tektronix 40 00 Features
The pan-zoom control consists of the following:
2. An outer pan knob.
3. An inner zoom knob.
4. Turn the zoom (inner) knob a few clicks
clockwise. The zoom feature sho uld turn
on. You are s eeing:
The entire acquisition in the top
window.
What you are zooming in on within the
gray top window brackets.
Thezoomedviewinthebottom
window.
30 Tektronix 4000 Oscilloscope Demo Instruction Manual
