Table2-15:BusCommands(cont.)

Commands Description

BUS:B<x>:POSition Sets or returns the position of the speciﬁed

bus waveform

BUS:B<x>:RS232C:BITRate Sets or r eturns the RS232 bit rate for the

speciﬁed bus

BUS:B<x>:RS232C:DATABits Sets or returns the number of bits for the

data frame

BUS:B<x>:RS232C:DELIMiter Sets or returns the RS232 delimiting value

for a packet on the speciﬁed bus

BUS:B<x>:RS232C:DISplaymode Sets or returns the display mode for the

speciﬁed bus display and event table

BUS:B<x>:RS232C:PARity Sets or returns parity for RS232 data

BUS:B<x>:RS232C:POLarity Sets or returns the RS232C polarity for the

speciﬁed bus

BUS:B<x>:RS232C:RX:SOUrce Sets or returns the RS232 RX source

BUS:B<x>:RS232C:TX:SOUrce Sets or returns the RS232 TX Source

BUS:B<x>:SPI{:CLOCK|:SCLK}:POLARity Sets or returns the SPI SCLK polarity

BUS:B<x>:SPI{:CLOCK|:SCLK}:SOUrce Sets or returns the SPI SCLK source

BUS:B<x>:SPI:DATA{:IN|:MISO}:POLARity Sets or returns the SPI MISO polarity

BUS:B<x>:SPI:DATA{:IN|:MISO}:SOUrce Sets or returns the SPI MISO source

BUS:B<x>:SPI:DATA{:OUT|:MOSI}:

POLARity

Sets or returns the SPI MOSI polarity

BUS:B<x>:SPI:DATA{:OUT|:MOSI}:SOUrce Sets or returns the SPI MOSI source

BUS:B<x>:SPI{:SELect|:SS}:POLARity Sets or returns the SPI SS polarity

BUS:B<x>:SPI{:SELect|:SS}:SOUrce Sets or returns the SPI SS source

BUS:B<x>:SPI:BITOrder Sets or returns the bit order for the speciﬁed

SPI bus

BUS:B<x>:SPI:DATA:SIZe Sets or returns the number of bits per word

for the speciﬁed SPI bus

BUS:B<x>:SPI:FRAMING Sets or returns the type of SPI framing

BUS:B<x>:SPI:IDLETime Sets or returns the SPI bus idle time in

seconds for the speciﬁed SPI bus

BUS:B<x>:STATE Turns the speciﬁed bus on and off

BUS:B<x>:TYPE Sets or returns the speciﬁed bus type

BUS:LOWerthreshold:CH<x> Sets or returns the lower threshold for each

channel

BUS:THReshold:CH<x> Sets or returns the threshold for a channel

BUS:UPPerthreshold:CH<x> Sets or returns the upper threshold for each

channel

BUS:THReshold:D<x> Sets or returns the threshold for digital

channel

2-14 MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
