Commands Listed in Alphabetical Order
MEASUREMENT:R
EFLEVEL:PERCENT:LOW?
might return
:MEASUREMENT:REFLEVEL:PERC ENT:LOW 10 indicating that the
percentage high reference level is set to 10% of HIGH.
MEASUrement
:REFLevel:PERCent:MID[1]
Sets or returns the percent (where 100% is equal to HIGH) that is used to calculate
the m id reference level when MEASUrement:REFLevel:METHod is set to
Percent. T
his command affects the results of period, frequency, delay, and all
cyclic measurements.
NOTE. this command affects the associated reference level parameter for all
MEASurements:IMMed and the four periodic measurements.
Group
Measurement
Syntax
MEASUrement:REFLevel:PERCe nt:MID[1] <NR3>
MEASUrement:REFLevel:PERCe nt:MID[1]?
Related Commands
MEASUrement:REFLevel:METHod
Arguments
<NR3> is the mid reference level, ranging from 0 to 100%. The default mid
reference level is 50%.
Examples
MEASUREMENT:REFLEVEL:PERCE NT:MID 1 60 sets the mid reference level
to 60% of H IGH.
MEASUREMENT:REFLEVEL:PERCE NT:MID? might return
:MEASUREMENT:REFLEVEL:PERC ENT:MID 65 indicating that the
percentage mid reference level is set to 65% of HIGH.
MEASUrement:REFLevel:PERCent:MID2
Sets or returns the percent (where 100% is equal to HIGH) that is used to
calculate the mid reference level for the second waveform spe cified when
MEASUrement:REFLevel:METHod is set to Percent. This command affects the
results of delay measurements.
NOTE. this command affects the associated reference level parameter for all
MEASurements:IMMed and the four periodic measurements.
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 2-213
