Giving Demos of Advanced Oscilloscope Features
4. Push the lower-bezel Bus button and turn
knob a to scroll through a list of buses that the
oscilloscope supports, such a s Parallel, I2C,
SPI, CAN, and RS-232. Select I2C.
Bus B1
I2C
Define
Inputs
Thresholds Include
R/W in
address
No
B1 Label
I2C
Bus Display Event Table
NOTE. The specific list of supported buses that
you see depends on the model of oscilloscope
used and the application m odules installed. The
MSO/DPO2000’s DPO2EMBD, MSO/DPO3000’s
DPO3EMBD, and MSO/DPO4000’s DPO4EMBD
modules support I2C.
5. Push the lower-bezel Define Inputs button.
Define
Inputs
6. On the side-menu, con fi rm that the SCLK
Input is set to channel 1 and that the SDA
Input is set to channel 2.
SCLK Input
a1
SDA Input
b2
7. Push the lower-bezel Thresholds button.
