Tektronix MSO2024B Programmer's Manual

Command Groups
Search Commands (cont.)
Command Description
SEARCH:SEARCH<x>:TRIGger:A:EDG E:
SOUrce
Sets or returns the source waveform for an
edge search
SEARCH:SEARCH<x>:TRIGger:A:LEVel Sets or r eturns the level for an edge search
SEARCH:SEARCH<x>:TRIGger:A:LEVel:
CH<x>
Sets or returns the level for an edge search
of the specified channel
SEARCH:SEARCH<x>:TRIGger:A:LEVel:
MATH
Sets or returns the m ath waveform level for
edge search
SEARCH:SEARCH<x>:TRIGger:A:LEVel:
REF<x>
Sets or returns the reference waveform level
for edge search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
FUNCtion
Sets or returns the logic operator for the logic
search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
INPut:CH<x>
Sets or returns the Boolean logic criteria for
the logic search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
INPut:CLOCk:EDGE
Sets or returns whether the clock edge is rise
or fall for a logic search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
INPut:CLOCk:SOUrce
Sets or returns the clock source definition for
logic search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
INPut:MATH
Sets or returns the Boolean logic criteria for
the logic search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
INPut:REF<x>
Sets or returns the Boolean logic criteria for
the logic search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
PATtern:INPut:CH < x>
Sets or returns the Boolean logic criteria for
the logic search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
INPut:D<x>
Sets or returns the waveform logic criteria for
a trigger search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
PATtern:INPut:M ATH
Sets or returns the Boolean logic criteria for
the logic search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
PATtern:INPut:D<x >
Sets or returns the logic criteria for a logic
pattern search to determine where to place
amark
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
PATtern:INPut:REF<x>
Sets or returns the Boolean logic criteria for
the logic search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
PATtern:WHEn
Sets or returns the condition for generating a
logic pattern search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
PATtern:WHEn:LESSLimit
Sets or returns the maximum time that the
selected pattern may be true
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
PATtern:WHEn:MORELimit
Sets or returns the minimum time that the
selected pattern may be true
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
THReshold:CH<x>
Sets or returns the channel threshold level
for an logic search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
THReshold:MATH
Sets or returns the math w aveform threshold
level for logic search
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 2-35
