Run application
software
Use ST1G or ST6G Serial Protocol Trigger Software to trigger and decode NRZ serial data (ST1G) and 8B/10B data on
high-speed ser
ial or data protocols (ST6G). Protocol triggering up to 6.25 GS/s (with ST6G).
Use SVP, SVM,a
nd SVE Spectral Analysis application to validate wideband designs and characterize wideband
spectral events.
Use SV O for flexible OFDM analysis, requires SVE.
Use SVT for settling time m easurements (frequency and phase), requires SVE.
Use USB to characterize USB 2.0 signals including mask testing and parametric testing.
Use USB3 to verify, characterize, debug, and compliance test USB 3.0 systems (requires option DJA).
Use VET to enable visual trigger and search.
Use XGBT for 10 GBASE-T Ethernet physical m edium attachment (PMA) physical-layer (PHY) electrical compliance
testing.
Follow the instructions provided with the
applicati
on software to install it. To run the
software, select Analyze and then select the
application.
MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series User Manual 167
