Tektronix PG 508 User Manual

TM 11-6825-2980-14
FO-16
Index
No. Qty 1 2 3 4 5 Name & Description
- • • ACTR ASSY INCLUDES:
-129 1 • • COVER,CAM SW:1.85 L X 0.876 H,AL
(ATTACHING PARTS)
-130 4 • • SCREW,MACHINE:4-40 X 0.25 INCH,PNH STL
-131 4 • • WASHER,LOCK:INTL,0.12 ID X 0.26"OD,STL
- - - * - - -
1 • • CONTACT,ELEC:GROUNDING
-132 2 • • NUT,PLAIN,HEX.:4-40 X 0.188 INCH,BRS
-133 1 • • SPRING,FLAT:GREEN COLORED
1 • • SPRING,FLAT:RED COLORED
-134 2 • • ROLLER,DETENT:
-135 1 • • BEARING,CAM SW:FRONT
(ATTACHING PARTS)
-136 1 • • RING,RETAINING:0.338 ID X 0.025" THK,STL
- - - * - - -
-137 1 • • ACTUATOR,SWITCH:CAM SWITCH
-138 1 • • SHAFT,CAM SW:OUTER CONCENTRIC,W/DRIVER
-139 4 • • NUT,PLAIN,HEX.:4-40 X 0.188 INCH,BRS
-140 1 • • BEARING,CAM SW:CENTER/REAR
1 • ACTUATOR ASSY CAM S:(S330A,B)
(ATTACHING PARTS)
-141 4 • SCR,ASSEM WSHR:4-40 X 0.312 INCH,PNH STL
- - - * - - -
- • • ACTR ASSY INCLUDES:
-142 1 • • COVER,CAM SW:1.55 L X 0.876 H,AL
(ATTACHING PARTS)
-143 4 • • SCREW,MACHINE:4-40 X 0.25 INCH,PNH STL
-144 4 • • SCREW,MACHINE:3-48 X 0.125,PNH,STL
- - - * - - -
1 • • CONTACT,ELEC:GROUNDING
-145 2 • • NUT,PLAIN,HEX.:4-40 X 0.188 INCH,BRS
-146 1 • • SPRING,FLAT:GREEN COLORED
1 • • SPRING,FLAT:RED COLORED
-147 2 • • ROLLER,DETENT:
-148 1 • • BEARING,CAM SW:FRONT
(ATTACHING PARTS)
-149 1 • • RING,RETAINING:0.338 ID X 0.025" THK,STL
- - - * - - -
-150 1 • • ACTUATOR,SWITCH:CAM SWITCH
-151 1 • • SHAFT,CAM SW:W/DRIVER
-152 4 • • NUT,PLAIN,HEX.:4-40 X 0.188 INCH,BRS
-153 1 • • BEARING,CAM SW:CENTER/REAR
1 • ACTR ASSY,CAM S: (S450 )
(ATTACHING PARTS)
-154 4 • SCR,ASSEM WSHR:4-40 X 0.312 INCH,PNH STL
- - - * - - -
- • • ACTR ASSY INCLUDES:
-155 1 • • COVER,CAM SW:1.95 L X 0.876 H,AL
(ATTACHING PARTS)
-156 4 • • SCREW,MACHINE:4-40 X 0.25 INCH,PNH STL
-157 4 • • WASHER,LOCK:INTL,0.12 ID X 0.26"OD,STL
- - - * - - -
1 • • CONTACT,ELEC:GROUNDING
-158 2 • • NUT,PLAIN,HEX.:4-40 X 0.188 INCH,BRS
-159 1 • • SPRING,FLAT:GREEN COLORED
1 • • SPRING,FLAT:RED COLORED
-160 2 • • ROLLER,DETENT:
-161 1 • • BEARING,CAM SW:FRONT
(ATTACHING PARTS)
-162 1 • • RING,RETAINING:0.338 ID X 0.025" THK,STL
-163 1 • • ACTUATOR,SWITCH:CAM SWITCH
-164 1 • • SHAFT,CAM SW:OUTER CNCTRC,W/DRIVER
5-14
