Clear and Sanitize Procedures
1.
Remove the front cover (if installed), the front panel trim, and the cabinet top.
2.
Remove the top EMI cover.
3.
Remove the hard drive and support bracket.
4.
Unplug the SATA cable from the hard drive.
5.
Remove the hard drive from the support bracket.
6.
Reinstall the support bracket.
7.
Reinstall the top EMI cover.
8.
Reinstall the cabinet top, the front panel trim, and front cover (if removed).
Removable Hard Drive
Procedure
The following procedure applies to instruments with Option 56 (Removable Hard Disk Drive) installed. For detailed
information on removing parts from the instrument, see the RSA5100B Series Real-Time Signal Analyzers Service Manual,
Tektronix part number 077-0903-XX.
WARNING.
Before doing this procedure, disconnect the power cord from the line voltage source. Failure to do so could
cause serious injury or death.
CAUTION.
To avoid damaging the hard drive, perform the following procedure in a static-safe environment with proper
electro-static discharge controls in place.
1.
Loosen the thumbscrews on the removable drive panel.
2.
Pull the removable drive out from the instrument.
6 RSA5100B Series Declassification and Security Instructions
