Command Descriptions
2–298
TDS Family Oscilloscope Programmer Manual
Y
n
max
YZEro YMUlt (y
n
max
YOFf)
specifies a normal waveform where one ASCII or binary data point is
transmitted for each point in the waveform record. Only y values are explicitly
transmitted. Absolute coordinates are given by:
X
n
0 XINcr (n PT_Off)
Y
n
YZEro YMUlt (y
n
YOFf)
might return , indicating that the MATH1 waveform data format is enveloped.
WFMPre:<wfm>:PT_Off
Returns the trigger point within the waveform record. On input <wfm> always
defaults to the reference location specified by DATa:DESTination regardless of
what is sent.
Waveform
= 0 to the recordlength, and is the position of the trigger point relative to
DATa:STARt when queried.
returns indicating the trigger position within the waveform record.
WFMPre:<wfm>:WFId
Returns information about the waveform such as input coupling, volts per
division, time per division, acquisition mode, and record length.
The WFMPre:<wfm>:WFId command is ignored on input.
Examples
Group
Syntax
Arguments
Examples
