Status and Events
TDS Family Oscilloscope Programmer Manual
3–15
Table 3–5: Execution Error Messages – EXE Bit 4 (Cont.)
Code Message
2203 Measurement error, No period, second waveform
2204 Measurement error, Low signal amplitude
2205 Measurement error, Low amplitude, second waveform
2206 Measurement error, Invalid gate
2207 Measurement error, Measurement overflow
2208 Measurement error, Waveform does not cross Mid Ref
2209 Measurement error, No second Mid Ref crossing
2210 Measurement error, No Mid Ref crossing, second waveform
2211 Measurement error, No backwards Mid Ref crossing
2212 Measurement error, No negative crossing
2213 Measurement error, No positive crossing
2214 Measurement error, No crossing
2215 Measurement error, No crossing, second waveform
2216 Measurement error, No crossing, target waveform
2217 Measurement error, Constant waveform
2218 Measurement error, Unused
2219 Measurement error, No valid edge – No arm sample
2220 Measurement error, No valid edge – No arm cross
2221 Measurement error, No valid edge – No trigger cross
2222 Measurement error, No valid edge – No second cross
2223 Measurement error, Waveform mismatch
2224 Measurement error, WAIT calculating
2225 Measurement error, No waveform to measure
2226 Null Waveform
2227 Positive and Negative Clipping
2228 Measurement error, Positive Clipping
2229 Measurement error, Negative Clipping
2230 Measurement error, High Ref < Low Ref
2235 Math error, Invalid math description
2236 Math error, Reference waveform is invalid
2237 Math error, Out of acquisition memory
2240 Invalid password
2241 Waveform requested is invalid
