TDS Family Oscilloscope Programmer Manual

Table 2–19: Trigger Commands (Cont.)

Header Description

TRIGger:MAIn:VIDeo:PAL

(TDS 5XXA, 6XXA, & 7XXA Option 05)

Select color or mono PAL

TRIGger:MAIn:VIDeo:SCAN

(TDS 4XXA Option 5)

Set video trigger scan rate

TRIGger:MAIn:VIDeo:SCANPeriod

(TDS 4XXA Option 5)

Set video trigger scan period

TRIGger:MAIn:VIDeo:SOUrce

Option 05

Select video trigger source

TRIGger:MAIn:VIDeo:STANdard

(TDS 5XXA, 6XXA, & 7XXA Option 05)

Select video trigger standard

TRIGger:MAIn:VIDeo:SYNc

(Option 05)

Select video trigger sync polarity

TRIGger:MAIn:VIDeo:SYStem

(TDS 4XXA Option 5)

Select video trigger class

TRIGger:MAIn:VIDeo:TIMe

(TDS 4XXA Option 5)

Set video trigger delay time

TRIGger:STATE? Return trigger system status
