Appendix A: Options and Accessories

A–2

TDS 684A, TDS 744A, & TDS 784A User Manual

Table A–1: Options (Cont.)

DescriptionLabelOption #

(TDS 7X4A)

130,000 record length

(TDS 7X4A)

Extend TDS 7X4A record length from 50,000 standard to

500,000 samples on one channel, 250,000 on two channels,

and 130,000 samples on three or four channels.

1R Rackmount Oscilloscope comes configured for installation in a 19 inch

wide instrument rack. For later field conversions, order

kit # 016-1136-00.

(TDS 7X4A)

Two active probes Add two 750 MHz P6205 active probes

24 Four passive probes Add four 500 MHz P6139A passive probes

26 Four active probes Add four 1 GHz P6245 active probes

2P Color printer Tektronix Phaser 200e, 300 dpi, thermal transfer, color printer.

It handles letter or A4 size Tektronix thermal paper and

transparencies. It can handle laser copy (plain) paper with the

ColorCoat Transfer roll.
