Appendix B: Algorithms

TDS 684A, TDS 744A, & TDS 784A User Manual

B–13

If all pairs straddle , use maxima. See Figure B–4.

The Burst Width measurement always uses both maxima and minima to

determine crossings.

MidRef

Both min and max

samples are above

MidRef, so use minima.

MidRef

Both min and max

samples are below

MidRef, so use maxima.

Figure B–4: Choosing Minima or Maxima to Use for Envelope Measurements
