Operating Interface Maps

TDS 684A, TDS 744A, & TDS 784A User Manual

2–7

To Operate a Menu



1 Press front-panel menu button. (Press SHIFT first if button label is blue.)

2 Press one of these buttons to select from main menu.

3 Press one of these buttons to select from side menu (if displayed).

4 If side menu item has an adjustable value (shown in reverse video), adjust it with the general purpose knob or keypad.
